Message log
The message log contains the following columns:
● Index
● Date and time
Displays the date and time in UTC format, including the local time difference.
YYYY-MM-DD HH:mm:ss +/-HH:mm
● Message class
● Context
● Message
Filtering the message log
You can filter the events shown in the message log according to the following categories.
Select one of the following settings from the drop-down list:
● Without filter
All information is shown.
● Errors only
Only errors are shown.
● Errors and warnings only
Only warnings and errors are shown.
File saving and formats
You can save the message log in CSV format (*.csv).
7.9 Graphical displays
Note
Functions for the graphical display of values are available in SIMATIC PDM, if they are
provided by the manufacturer of the device description.
Functions
7.9 Graphical displays
Help for SIMATIC PDM (V8.2)
Operating Manual, 02/2014, A5E33203676-AA 139
