Setting the printer options
Note
Note the following:
● The printer options depend on your computer's operating system and on the printer being
used.
● The file is sent to the default printer.
● If the printout has more than one page, two periods are printed after the page number in
the bottom right corner of the page. The last page does not have these periods, indicating
no more pages are to follow.
Requirements
● SIMATIC PDM is open.
● In the structure view, an object is selected in the root folder of a device.
You can find information on the structure view in the section "Stand-alone device view
(Page 65)".
Procedure
1. Select the menu command File > Print or click the "Print" button .
The "Print" dialog box opens.
2. Select the required options.
3. Click "OK".
7.2.6 Cleaning the project (reorganization)
PDM objects can be contained in copied SIMATIC projects. If SIMATIC PDM will no longer be
used in the project, you can remove the requirement for TAG licenses in the project using the
"Reorganize" function.
Note
SIMATIC PDM must be closed before you use the "Reorganize" function.
The time it takes to perform reorganization depends on the data movement required, and it
can be a long time. The function is therefore not carried out automatically (for example, when
closing a project).
Procedure
In SIMATIC Manager, select the menu command File > Reorganize.
Functions
7.2 Project editing
Help for SIMATIC PDM (V8.2)
76 Operating Manual, 02/2014, A5E33203676-AA
