Selecting check boxes
The loaded object is the one which is currently selected in SIMATIC PDM in parameter
assignment mode.
Comparison object Check box Additional information
Online data of the
loaded object
Compare with online data of
the loaded object
1. Click "Apply". The online data is read in
from the device.
2. Click "OK".
Offline data of another
object
Compare with offline data of
another object
1. Click "Select object" dialog box
(Page 169).
The "Select object" dialog box (Page 169)
dialog box opens.
2. Select the comparison object that you want
to search for.
3. Click "Apply". The online data or offline
data of the comparison object is read.
4. Click "OK".
Online data of another
object
Compare with online data of
another object
Display
The Parameter table (Page 61) is expanded by the columns for value, unit and status of the
comparison object. These columns cannot be edited.
Display Meaning
No color difference in columns The respective parameters and the associated values are
identical for both devices.
A yellow box in the value or unit
column of the comparison object.
The parameter is available in both devices. The associated
values are different.
Yellow box in the parameter column The parameter is only available in one device.
A plant-specific value check must be carried out. Automatic
analysis is not possible.
The value has been changed.
8.3.3.3 "Select object" dialog box
Use this dialog box to select the required comparison objects or partner objects.
8.3.4 Assign address and TAG
In the "Assign address and TAG" dialog box, you can assign new addresses and device names
to a device:
Menus and dialog boxes in SIMATIC PDM
8.3 "Device" menu
Help for SIMATIC PDM (V8.2)
Operating Manual, 02/2014, A5E33203676-AA 169
