Errors and messages
During the loading, all errors and messages are shown immediately. Any errors occurring in
a device do not cause the entire action to be aborted; they only apply to the device that is
currently being processed. Errors and other messages are saved and can be displayed at a
later time.
Suppressing message dialogs
You can suppress message dialogs during the loading. Select the "Execute 'Load' without info
dialogs" check box. You can find additional information using the Options > SIMATIC PDM >
Settings > The "Load" tab (Page 213) menu command.
Additional information
You can find information on loading FF devices in the
PCS 7 FOUNDATION Fieldbus
commissioning manual
See also
"Download to Device - <...>" dialog box (Page 164)
8.3.1.1 "Download to Device - <...>" dialog box
In this dialog box, you enter the desired settings for downloading the configuration data to the
devices.
"Select" area
If the object selected prior to loading contains subordinate objects, you can load the
configuration to all subordinate objects. Use the option buttons in the "Select" area to make
your selection.
● Object
● Object with all subordinate objects
● Object with all subordinate objects and networks
Field Explanations/operating instructions
Object Loads only the data of the selected object.
Object with all
subordinate objects
Loads the data of the selected object, including all subordinate objects.
Note:
The tree structure can be expanded and collapsed for objects with
subordinate objects.
Object with all
subordinate objects and
networks
Loads the data of the selected object, including all subordinate
substructures.
"Load changed parameters only" check box
If this check box is selected, only the changed parameters are transmitted to the devices.
Menus and dialog boxes in SIMATIC PDM
8.3 "Device" menu
Help for SIMATIC PDM (V8.2)
164 Operating Manual, 02/2014, A5E33203676-AA
