The "Redundancy" area is displayed for field devices which are capable of redundant
interconnection.
Table 9-2 "Redundancy" area
Field Explanations/operating instructions
"Redundancy activated"
check box
There is a redundant partner device for this device.
Corresponding slave The redundant partner device can be found via this field.
* Entry can be changed.
See also
Connecting field devices to a redundant bus system (Page 103)
"Select object" dialog box (Page 104)
9.1.2.5 "Document Manager" tab
Use this tab to assign documents to a PDM object.
Actions on the "Document Manager" tab
Action To execute
File 1. Click the "..." button.
2. Navigate to the document required.
3. Click "Open".
The storage path and file name of the selected file are
displayed in the "File" box.
Title Enter a name for the document.
Test whether a document can be
displayed
Select the menu command Open.
Remove a document from the list. Select the menu command Reset.
Open documents
To open the documents, select the SIMATIC PDM menu command Help > Document
Manager. Select the required document from the submenu.
Menus and dialog boxes for SIMATIC PDM in the SIMATIC Manager
9.1 "Edit" menu
Help for SIMATIC PDM (V8.2)
Operating Manual, 02/2014, A5E33203676-AA 199
