Functions in product package
Functions SIMATIC PDM
Single Point STEP 7 PCS 7
Project functions
● Create online ● ● ●
● TAG options used - ● ●
● Network view ● ● ●
● Plant view ● ● ●
● Export / import devices - ● ●
● HW Config - ● ●
● Integration in STEP 7 - ● ●
Communication functions
● PROFIBUS ● ● ●
● PROFINET ● ● ●
● FOUNDATION Fieldbus - ○ ○
● MODBUS ● ● ●
● S7 DSGW - ○ ●
● HART modem ● ● ●
● HART interface network ● ● ●
● HCF HART server - ○ ○
● HART SHC mode
(communication acceleration)
● ● ●
Device functions
● Use of SIMATIC PDM options - ● ●
● Saving parameters ● ● ●
● Log (audit trail) - ● ●
LifeList functions
● Scan from HW Config - ● ●
● Device diagnostics - ● ●
● Define scan area ● ● ●
● Scan from network view ● ● ●
SIMATIC PDM Single Point
SIMATIC PDM Single Point can be used for a single device. SIMATIC PDM Single Point cannot
be extended with other options.
Using SIMATIC PDM
2.6 Product structure
Help for SIMATIC PDM (V8.2)
Operating Manual, 02/2014, A5E33203676-AA 19
