Visible columns Displayed information
Device name* Device name
Manufacturer* Manufacturer
Communication* Communication type for the connection to the field device
Device class* Hierarchical name of the device type (e.g. flow sensor)
New version* Version of the device description which was read in from a device description library
Integrated version* Version of the device description that is integrated in SIMATIC PDM
Integrated on Date on which a device description was integrated into SIMATIC PDM
Description Descriptive text from the device description
Type ID ID for a device type in hexadecimal format
GSD file Name of the communication description file
New EDD revision Revision of the imported device description
Integrated EDD revision Revision of the integrated device description
New device revision Device revision of the device description that was read from a device description library.
Devices of the associated device type with this device revision can be interpreted in SIMATIC
PDM.
Integrated device revision Device revision of the device description which is integrated in SIMATIC PDM. Devices with
this device revision of the device type can be interpreted in SIMATIC PDM.
Device library Revision of the device description library (EDD library) from which the device description of
the associated device has been read in
* Selected by default
Use the following buttons to speed up the configuration process:
● Select all (select)
● Deselect all
● Reset selection
"Actions during device integration" area
Check box Explanations/operating instructions
Semantic check If this check box is selected, the Device Integration Manger checks
the device description files for semantic errors during the integration
process.
Compile DD after import If this check box is selected, the individual device descriptions are
compiled for SIMATIC PDM during the actual integration process.
Note:
Integrated device descriptions that have not yet undergone
compilation are compiled automatically when a device type is
opened in SIMATIC PDM for the first time.
Menus and dialog boxes for SIMATIC PDM in the SIMATIC Manager
9.4 "Options" menu
Help for SIMATIC PDM (V8.2)
214 Operating Manual, 02/2014, A5E33203676-AA
