Product overview
1.2 What is the ET 200S distributed I/O system?
EIP-200S Ethernet/IP Adapter Distributed I/O System
10 System Manual, 06/2018, A5E44345053-AB
Electronic module Is connected to the terminal module and determines
the function:
• Digital input modules with 24 VDC, 120/230 VAC
and NAMUR
• Digital output modules with 24 VDC and
120/230 VAC
• Relay modules
• Analog input modules with voltage, current, and
resistance measurement; thermal resistance; and
thermocouples
• Analog output modules for voltage and current
Terminating module Terminates the ET 200S and can be used to carry 6
reserve fuses (5 mm x 20 mm).
Shield contact For connecting cable shields.
Slot number labels For identifying the slots on the terminal module.
Color identification labels Permit customer and country-specific identification of
the terminals on the terminal module.
Labeling sheet (DI A4, perfo-
rated, foil)
For machine labeling or printing - 80 strips per label-
ing sheet
