EIP-200S Ethernet/IP Adapter
2.6 Device profile: supported CIP objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
37
Interface Flags attribute
0 Link Status Indicates whether the IEEE 802.3 communications interface is
connected to an active network:
0 = inactive link
1 = active link
The determination of link status is implementation specific
1 Half/Full Duplex Indicates the duplex mode currently in use:
0 = interface is running half duplex
1 = interface is running full duplex
Note that if the Link Status flag is 0, the value of the half/full duplex
2 - 4 Negotiation Status Indicates the status of link autonegotiation:
0 = autonegotiation in progress
1 = autonegotiation and speed detection failed. Using default val-
ues for speed and duplex
2 = autonegotiation failed but detected speed. Duplex was faulted.
3 = successfully negotiated speed and duplex
4 = autonegotiation not attempted. Forced speed and duplex.
5 Manual Setting Re-
quires Reset
0 = interface can activate changes to link parameters (autonegoti-
ate, duplex mode, interface speed) automatically.
1 = device requires a Reset service be issued to its Identity Object
in order for the changes to take effect.
6 Local Hardware Fault 0 = interface detects no local hardware fault
1 = local hardware fault detected
Interface Counters (STRUCT of)
In Octets UDINT Octets received on the interface
Unicast packets received on the interface
Non-unicast packets received on the interface
Inbound packets received on the interface but discarded
In Errors UDINT Inbound packets that contain errors (does not include In
Inbound packets with unknown protocol
Octets sent on the interface
Unicast packets sent on the interface
Non-unicast packets sent on the interface
Outbound packets discarded
Outbound packets that contain errors
