2.7 Device profile: vendor-specific objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
51
Attribute 14-21 [Channel<n>Type] details
The Channel<n>Type attributes, listed in the following table, provide additional detail when
the corresponding Channel<n>Status is reporting an error.
Status code
Text
Description
0 N/A Reported when corresponding Channel<n>Status is
reporting "No error"
1 Bit 1-bit channel
2
2 Bit
2-bit channel
3 4 Bit 4-bit channel
4
Byte
8-bit channel
5
Word
16-bit channel
6
2 Word
32-bit channel
7 - 255
Reserved
Attribute 22-53 [ParamByte(n)] details
The ParamByte attributes provide single byte (USINT) access to the first 32 elements of the
Parameters attribute (Attribute 3) for access via tools not supporting complex data type
representation. Modification of the Parameters attribute will affect all the corresponding
ParamByte attributes and visa versa. The EIP-200S Ethernet/IP Adapter limits the slot
object’s ParameterSize attribute to a maximum value of 32.
Common services for the Slot Object
Service
code
Implemented for
Service name
Class
Instance
0x0E
No
Yes
Get_Attribute_Single
0x10
No
Yes
Set_Attribute_Single
