Installation and wiring
3.4 Inserting and identifying the electronic modules
EIP-200S Ethernet/IP Adapter Distributed I/O System
56 System Manual, 06/2018, A5E44345053-AB
Removing electronic modules
To remove electronic modules, follow the steps below:
1. Simultaneously press the two release buttons on the top and bottom of the electronic
module.
2. Pull the electronic module out from the terminal module at the front.
The following diagram illustrates removing electronic modules:
