Siemens SIMATIC TD 200 User Manual

D-20
SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
Table D-2 Required Display Characters for Each Display Format
Value Size
Number of
Digits to the
Right of the
Decimal Point
Number of Display
Characters
(maximum)
Example
0 5 12345
1 to 4 6 1234.5 to 1.2345
Unsigned Word
5 7 0.12345
g
6 8 0.012345
7 9 0.0012345
0 6 -12345
1 to 4 7 -1234.5 to -1.2345
Signed Word
5 8 -0.12345
g
6 9 -0.012345
7 10 -0.0012345
0 10 1234567891
Unsigned DWord
1 to 7 11
123456789.1 to
123.4567891
0 11 -1234567891
Signed DWord
1 to 7 12
-123456789.1 to
-123.4567891
Real
0 Up to 20 -1234567
R
ea
l
(Floating Point)
DWord
1 to 7 Up to 20
12345.6 to
0.0123456
TD 200 Parameters and Messa
g
es
