Siemens SIMATIC TD 200 User Manual

3-6
SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
3.3 Viewing Messages
With the View Messages menu, you can sequentially view all of the messages and
process values stored in the S7-200 CPU. Press the UP and DOWN arrows to
display the second (and subsequent) message from the programmable logic
controller.
Note
You cannot edit process values while you are in the View Messages menu option.
Accessing the Menu
To access the View Messages menu, perform the following steps.
Key Action Display
1.
ESC
The TD 200 enters the Menu mode.
VIEW MESSAGES
MENU MODE:
2.
ENTER
The TD 200 enters the View Messages
menu.
YOUR MESSAGE
Use the UP and DOWN arrows to scroll through messages stored in the S7-200
CPU. You cannot edit values in this mode. You can only edit values in the display
mode.
Note
Pressing ESC at any time when you are viewing messages aborts the message
display and returns you to the Display Message mode. The TD 200 automatically
returns to the Display mode after one minute if no keys are pressed.
Operatin
g
the TD 200
