Entering the Parameter Block Address
The Setup Menu allows you to designate a V memory location where the
parameter block (or an offset to the location of the parameter block) is stored in the
CPU. The default parameter block address is V0. You can enter any V memory
address up to V999.
Use the following procedure to enter the V memory address of the parameter block
(or the location of the offset to the parameter block):
Key Action Display
1.
ESC
The TD 200 enters the Menu mode.
VIEW MESSAGES
MENU MODE:
2. The TD 200 scrolls down the menu
options five times.
TD 200 ADDRESS 1
SETUP MENU:
3. The TD 200 scrolls down the Setup
Menu to the parameter block address
option.
PARM ADDRESS 0
SETUP MENU:
4.
ENTER
Press ENTER to move the cursor to the
address field. Use the up or down
arrow keys to display the correct
address.
SETUP MENU:
PARM ADDRESS 0
5.
ENTER
Press ENTER to store the V memory
address of the parameter block.
SETUP MENU:
PARM ADDRESS 30
Note
Pressing ESC at any time while you are entering the address of the parameter
block aborts the edit and restores the previous address for the parameter block.
