SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
Note
Pressing ESC at any time while you are setting the network address for the TD200
aborts the edit and restores the previous value of the network address.
Selecting the CPU Address
The Setup menu allows you to enter the network address of the CPU. (The default
address for the CPU is 2.) Use the following procedure to change the network
address for the CPU:
Key Action Display
1.
ESC
The TD 200 enters the Menu mode.
VIEW MESSAGES
MENU MODE:
2. The TD 200 scrolls down the menu
options five times.
TD 200 ADDRESS 1
SETUP MENU:
3. The TD 200 scrolls down the Setup
Menu to the CPU address option.
CPU ADDRESS 2
SETUP MENU:
4.
ENTER
Press ENTER to move the cursor to the
address field. Use the up or down
arrow keys to display the correct
address.
SETUP MENU:
CPU ADDRESS 2
5.
ENTER
Press ENTER to store the new address
for the CPU.
SETUP MENU:
CPU ADDRESS 3
Note
Pressing ESC at any time while you are setting the network address of the CPU
aborts the edit and restores the previous value of the CPU address.
Operatin
the TD 200
