A-7
SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
A.5 ALT Key Combinations for International and Special Characters for
the TD 200 Original Character Set
When entering certain international and special characters in the
STEP 7-Micro/WIN TD 200 Configuration Wizard with the TD standard character
set, they may not appear correctly on the TD 200 display. If the characters do not
display correctly, use the ALT key and number combinations shown in Table A-3 to
enter the characters in the TD 200 Configuration Wizard.
Table A-3 ALT Key Combinations for International and Special Characters
Character
ALT Key Combination Character ALT Key Combination
ü Alt-0129
ñ
Alt-0164
ä Alt-0132
Ω
Alt-0234
æ Alt-0145
Σ
Alt-0228
Æ Alt-0146
Π
Alt-0227
å Alt-0134
Alt-0157
ö Alt-0148
Alt-0195 (left arrow ←)
Å Alt-0143
Alt-0180 (right arrow →)
° Alt-0248 Alt-0200 (single bar)
α Alt-0224 Alt-0201 (double bar)
ß Alt-0225 Alt-0202 (triple bar)
Alt-0238 Alt-0203 (four bars)
Alt-0230 Alt-0204 (five bars)
Alt-0229 ↑ Alt-0194 (up arrow)
¢ Alt-0155
