Adjusting the Display Contrast
The Setup Menu allows you to adjust the Display Contrast for the TD 200. The
Display Contrast allows the user to optimize the display for different viewing angles
and lighting conditions. The default contrast value is 12. Values greater than 12
make the display darker. Values less than 12 make the display lighter.
Use the following procedure to select the Display Contrast for the TD 200:
Key Action Display
1.
ESC
The TD 200 enters the Menu mode.
VIEW MESSAGES
MENU MODE:
2. The TD 200 scrolls down the menu
options five times.
TD 200 ADDRESS 1
SETUP MENU:
3. The TD 200 scrolls down the Setup
menu to the contrast option.
CONTRAST 12
SETUP MENU:
4.
ENTER
Press ENTER to move the cursor to the
contrast field. Use the up or down
arrow keys to change the contrast.
SETUP MENU:
CONTRAST 12
5.
ENTER
Press ENTER to store the new contrast
value for the TD 200.
SETUP MENU:
CONTRAST 14
Note
Pressing ESC at any time while you are changing the Display Contrast for the
TD 200 aborts the edit and restores the previous value.
Operatin
g
the TD 200
