Selecting the GAP Factor
The Setup menu allows you to select the GAP Factor for the TD 200. This setting
tells the TD 200 how often to check for other network master devices. The default
setting of 10 causes the TD 200 to check once every 10 messages. A setting of 1
would cause the TD 200 to check for other masters after every message.
Use the following procedure to select the GAP Factor for the TD 200:
Key Action Display
1.
ESC
The TD 200 enters the Menu mode.
VIEW MESSAGES
MENU MODE:
2. The TD 200 scrolls down the menu
options five times.
TD 200 ADDRESS 1
SETUP MENU:
3. The TD 200 scrolls down the Setup
menu to the GAP Factor option.
GAP FACTOR 10
SETUP MENU:
4.
ENTER
Press ENTER to move the cursor to the
GAP Factor field. Use the up or down
arrow keys to change the GAP Factor.
SETUP MENU:
GAP FACTOR 10
5.
ENTER
Press ENTER to store the new GAP
Factor for the TD 200.
SETUP MENU:
GAP FACTOR 12
Note
Pressing ESC at any time while you are selecting the GAP Factor for the TD 200
aborts the edit and restores the previous GAP Factor.
