A-4
SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
A.3 Technical Specifications
Table A-1 Technical Specifications for the TD 200
Description Technical Specifications
TD 200
Order number 6ES7 272-0AA20-0YA0
Dimensions
(H x W x D)
76 x 148 x 28 mm (3 x 5.8 x 1.1 in.)
Weight approx. 0.19kg (without accessories)
Display STN-Graphic Display with 181 x 33 (Columns x Rows)
LED backlight
Keyboard Membrane keypad / 9 keys / Tab inserts for customer specific labeling
PG - PLC interface RS 485 (PPI); 9.6 / 19.2 / 187.5 Kbits/s
Supply voltage (U
N
) 24VDC, (15VDC...30VDC, safety extra low voltage, supplied by PLC, mains
adapter or a 24VDC external supply). The TD 200 has no integrated means
of protection against strong interference pulses in the s range (surge im-
pulse). If the power being supplied has no appropriate means of protection
then a surge voltage protector should be preconnected.
Current consumption (I
N
) typ. 70 mA, (terminating resistors switched off),
max. 120 mA at U
N
24V (2A fuse in TD 200).
Inrush current max. 0.6 A / 15 ms
Degree of protection IP 65 (mounted on the front of the panel)
IP 20 (mounted on the casing)
Safety
VDE regulation VDE 0805, EN 60950, IEC 950
Noise emission <45dB(A) to DIN 45635 (no fan)
Electromagnetic compatibility (EMC)
Emitted interference
Limit class
B to EN 55022 = CISPR 22
Noise immunity on signal
lines
2kV (to IEC 1000-4-4; Burst)
Noise immunity to
discharge of static
electricity
6kV Contact discharge (to IEC 1000-4-2; ESD)
8kV Air discharge (to IEC 1000-4-2; ESD)
Conducted interference
on DC power supply line
2kV (to IEC 1000-4-4; Burst)
1kV
1)
(to IEC 1000-4-5; µs-impulse (Surge);
(line against line))
2kV
1)
(to IEC 1000-4-5; µs-impulse (Surge);
(line against earth))
1)
Power supplies with the same voltage can only be used with additional
means of protection. For example, a surge voltage protector available
from the Dehn company, type RZ/E 24 V-, order No. 917 204
