3-20
SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
Setting the Highest Station Address
The Setup Menu allows you to set the highest station address for the TD 200. This
setting tells the TD 200 which network addresses to check when looking for other
network master devices. The default highest station address is 31. This means that
the TD 200 checks addresses 0 through 31 when looking for other network
masters. This setting should only be changed when there are more than 32 master
devices on the network.
Note
At 9600 or 19.2 kbaud, the highest station adress may need to be increased, even though
the network does not contain more than 32 masters. Increasing the highest station address
allows more time for the masters to transmit messages.
Use the following procedure to change the highest station address for the TD 200:
Key Action Display
1.
ESC
The TD 200 enters the Menu mode.
VIEW MESSAGES
MENU MODE:
2. The TD 200 scrolls down the menu
options five times.
TD 200 ADDRESS 1
SETUP MENU:
3. The TD 200 scrolls down the Setup
Menu to the highest station option.
HIGHEST STATION 31
SETUP MENU:
4.
ENTER
Press ENTER to move the cursor to the
address field. Use the up or down
arrow keys to display the correct
address.
SETUP MENU:
HIGHEST STATION 31
5.
ENTER
Press ENTER to store the new highest
station address for the TD 200.
SETUP MENU:
HIGHEST STATION 2
Note
Pressing ESC at any time while you are setting the highest station address for the
TD 200 aborts the edit and restores the previous highest station address.
Operatin
g
the TD 200
