Siemens SIMATIC TD 200 User Manual

1-5
SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
29.3 mm
(1.16 in.)
0.6 mm
(0.02 in.)
Material thickness .18 mm (0.007 in.)
Text Viewing Areas
5 places
Label Insert
16.8 mm
(0.66 in.)
11.9 mm
(0.47 in.)
0 mm
(0 in.)
0 mm
(0 in.)
11.9 mm
(0.47 in.)
20 mm
(0.78 in.)
33.3 mm
(1.31 in.)
42.3 mm
(1.66 in.)
55.8 mm
(2.2 in.)
64.9 mm
(2.55 in.)
78.4 mm
(3.1 in.)
87.4 mm
(3.44 in.)
100.9 mm
(3.95 in.)
15.1 mm
(0.59 in.)
14.2 mm
(0.56 in.)
28.7 mm
(1.13 in.)
101.6 mm
(4.00 in.)
Figure 1-3 Customizing the TD 200 Keyboard
SIEMENS TD 200
Label Insert
SIEMENS TD 200
Insert corner of label insert into
semi-circular cutout.
Rotate label downward.
Lift front panel.
Slide label insert
into TD 200 front panel
Semi-circular Cutout
Figure 1-4 Inserting Customized Label
Product Overview and Installation
