Technical data
15.2 Technical specifications of the SIMOCODE pro C / pro S / pro V PB / pro V MR basic units
SIMOCODE pro
334 System Manual, 05/2019, A5E40507475002A/RS-AD/004
Technical specifications of the SIMOCODE pro C / pro S / pro V PB / pro V MR basic units
SIMOCODE pro C
(3UF7000) / pro S (3UF7021).
Measurement conditions: Room temperature,
combination of basic unit, current acquisition
module and operator panel, each with 2 LEDs
switched on and active inputs and outputs,
active thermistor, and 1.5 MBd bus
SIMOCODE pro C basic unit:
SIMOCODE pro S basic unit:
4.7 VA / 2.5 W 2.1 W
SIMOCODE pro V PB (3UF7010) / pro V MR
(3UF7012):
Measurement conditions: Room temperature,
combination of basic unit, current/voltage
acquisition modules and operator panel with
display, each with 2 LEDs switched on and
active inputs and outputs, active thermistor, and
1.5 MBd bus transmission rate
SIMOCODE pro V PB basic unit:
SIMOCODE pro V MR basic unit:
8.3 VA / 3.6 W 2.6 W
Rated insulation voltage U
i
300 V (at pollution degree 3)
Rated impulse withstand voltage U
imp
Power failure backup time
(longer power
failures lead to shutdown of the relay outputs
(monostable))
SIMOCODE pro C
24 V DC
Typ. 50 ms
SIMOCODE pro S Typ. 50 ms
SIMOCODE pro V - 24 V DC Typ. 50 ms
SIMOCODE pro V - 110 V -
Typ. 200 ms
Number Monostable relay outputs:
3 (SIMOCODE pro C, pro V)
Function Isolated NO contacts (NO contact response parameterizable via internal
signal conditioning), 2 relay outputs connected to common potential, one
separate relay output, freely-assignable to control functions
(e.g. line, star or delta contactor or operating state status information.)
Stipulated short-circuit protection for auxiliary
contacts (relay outputs)
• 6 A fuse inserts, operational class gG; 10 A quick-response
(IEC 60947-5-1)
• Miniature circuit breaker 1.6 A, C characteristic (IEC 60947-5-1)
• Miniature circuit breaker 6 A, C characteristic (Ik < 500 A)
Rated uninterrupted current 5 A
