Description of the motor
2.5 Selection and ordering data
1FW3 complete torque motors
32 Configuration Manual, 08/2020, A5E46027705B AA
Motor Module
The Motor Modules assigned to 1FW3 motors are dimensioned for a rated motor current I
N
.
If the full motor stall torque is required, then you must dimension the Motor Modules
according to the motor stall current (I
0
).
If the motor is temporarily operated at operating points above the S1 characteristic, you must
take into consideration the actual current demand of the motors and appropriately select the
Motor Modules.
Note
Configuration tool
The SIZER for SIEMENS Drives engineering tool supports you when dimensioning and
engineering the drive system (see Chapter "
SIZER configuration tool (Page 91)").
Structure of the Article Nos. for the Motor Modules
Suitable Motor Module
Table 2- 10 Assignment: Motor type - Motor Module
Motor type
Rated current /
stall current
I
N
[A] / I
0
[A]
Order designation (Article No.)
Motor Module SINAMICS S120
Rated current
Motor Module
I
N
[A]
Rated pulse frequency
Motor
f
pulseN
[kHz]
Line supply voltage of 400 V 3 AC, Active Line Module (V
mot
= 425 V)
*)
1FW315☐
1FW3150-1☐H
7.2 / 7.3
6SL3120-1TE21-0AD☐
9
4
1FW3150-1☐L
11 / 11.5
6SL3120-1TE21-8AC☐
18
4
1FW3150-1☐P
17 / 17.5
6SL3120-1TE21-8AC☐
18
4
1FW3152-1☐H
14 / 15
6SL3120-1TE21-8AC☐
18
4
1FW3152-1☐L
22 / 22.5
6SL3120-1TE22-4AC☐
24
4
1FW3152-1☐P
32.5 / 33.5
6SL3120-1TE24-5AC☐
45
4
1FW3154-1☐H
20.5 / 21.5
6SL3120-1TE22-4AC☐
24
4
1FW3154-1☐L
32 / 33
6SL3120-1TE24-5AC☐
45
4
1FW3154-1☐P
47.5 / 49
6SL3120-1TE26-0AC☐
60
4
1FW3155-1☐H
28 / 29
6SL3120-1TE23-0AC☐
30
4
1FW3155-1☐L
43 / 45
6SL3120-1TE24-5AC☐
45
4
1FW3155-1☐P
64 / 67
6SL3120-1TE28-5AA☐
85
4
1FW3156-1☐H
34 / 35
6SL3120-1TE24-5AC☐
45
4
1FW3156-1☐L
53 / 55
6SL3120-1TE26-0AC☐
60
4
1FW3156-1☐P
76 / 80
6SL3120-1TE28-5AA☐
85
4
