Description of the motor
2.5 Selection and ordering data
1FW3 complete torque motors
Configuration Manual, 08/2020, A5E46027705B AA
33
Motor type
Rated current /
stall current
I
N
[A] / I
0
[A]
Order designation (Article No.)
Motor Module SINAMICS S120
Rated current
Motor Module
I
N
[A]
Rated pulse frequency
Motor
f
pulseN
[kHz]
Line supply voltage of 400 V 3 AC, Active Line Module (V
mot
= 425 V)
*)
1FW320☐ Standard
1FW3201-1☐E
13 / 13
6SL3120-1TE21-8AC☐
18
4
1FW3201-1☐H
23 / 24
6SL3120-1TE22-4AC☐
24
4
1FW3201-1☐L
37 / 38
6SL3120-1TE24-5AC☐
45
4
1FW3202-1☐E 21 / 22 6SL3120-1TE22-4AC☐ 24 4
1FW3202-1☐H
37 / 39
6SL3120-1TE24-5AC☐
45
4
1FW3202-1☐L
59 / 62
6SL3120-1TE26-0AC☐
60
4
1FW3203-1☐E
30 / 32
6SL3120-1TE24-5AC☐
45
4
1FW3203-1☐H
59 / 62
6SL3120-1TE26-0AC☐
60
4
1FW3203-1☐L
92 / 100
6SL3120-1TE31-3AA☐
132
4
1FW3204-1☐E
40 / 42
6SL3120-1TE24-5AC☐
45
4
1FW3204-1☐H
74 / 77
6SL3120-1TE28-5AA☐
85
4
1FW3204-1☐L
118 / 129
6SL3120-1TE31-3AA☐
132
4
1FW3206-1☐E
65 / 68
6SL3120-1TE28-5AA☐
85
4
1FW3206-1☐H
118 / 121
6SL3120-1TE31-3AA☐
132
4
1FW3206-1☐L
169 / 189
6SL3120-1TE32-0AA☐
200
4
1FW3208-1☐E
84 / 88
6SL3120-1TE28-5AA☐
85
4
1FW3208-1☐H
153 / 160
6SL3120-1TE32-0AA☐
200
4
1FW3208-1☐L
226 / 256
6SL3320-1TE32-6AA☐
260
2
1FW320☐ High Speed
1FW3201-3☐P
37 / 38
6SL3120-1TE24-5AC☐
45
4
1FW3201-3☐S
50 / 54
6SL3120-1TE26-0AC☐
60
4
1FW3202-3☐P
69 / 72
6SL3120-1TE28-5AA☐
85
4
1FW3202-3☐S
92 / 102
6SL3120-1TE31-3AA☐
132
4
1FW3203-3☐P
96 / 102
6SL3120-1TE31-3AA☐
132
4
1FW3203-3☐S
131 / 149
6SL3120-1TE31-3AA☐
132
4
1FW3204-3☐P
137 / 145
6SL3120-1TE32-0AA☐
200
4
1FW3204-3☐S
191 / 220
6SL3120-1TE32-0AA☐
200
4
1FW3206-3☐P
192 / 210
6SL3120-1TE32-0AA☐
200
4
1FW3206-3☐S
270 / 330
6SL3320-1TE33-1AA☐
310
2
1FW3208-3☐P
270 / 295
6SL3320-1TE33-1AA☐
310
2
1FW3208-3☐S
385 / 470
6SL3320-1TE35-0AA☐
490
2
1FW328☐ Standard
1FW3281-2☐E
82 / 84
6SL3120-1TE28-5AA☐
85
4
1FW3281-2☐G
126 / 131
6SL3120-1TE31-3AA☐
132
4
1FW3283-2☐E
115 / 116
6SL3120-1TE31-3AA☐
132
4
1FW3283-2☐G
176 / 181
6SL3120-1TE32-0AA☐
200
4
1FW3285-2☐E
160 / 163
6SL3120-1TE32-0AA☐
200
4
1FW3285-2☐G
244 / 251
6SL3320-1TE32-6AA☐
260
2
