Siemens SIMOTICS T-1FW3 User Manual

Description of the motor
2.5 Selection and ordering data
1FW3 complete torque motors
34 Configuration Manual, 08/2020, A5E46027705B AA
Motor type
Rated current /
stall current
I
N
[A] / I
0
[A]
Order designation (Article No.)
Motor Module SINAMICS S120
Rated current
Motor Module
I
N
[A]
Rated pulse frequency
Motor
f
pulseN
[kHz]
Line supply voltage of 400 V 3 AC, Active Line Module (V
mot
= 425 V)
*)
1FW3287-2☐E
230 / 234
6SL3320-1TE32-6AA☐
260
2
1FW3287-2☐G
352 / 365
6SL3320-1TE33-8AA☐
380
2
1FW328☐ High Speed
1FW3281-3☐J
188 / 200
6SL3120-1TE32-0AA☐
200
4
1FW3281-3☐M 256 / 291 6SL3320-1TE33-1AA☐ 310 2
1FW3281-3☐P
315 / 403
6SL3320-1TE33-8AA☐
380
2
1FW3283-3☐J
275 / 292
6SL3320-1TE33-1AA☐
310
2
1FW3283-3☐M
357 / 402
6SL3320-1TE33-8AA☐
380
2
1FW3283-3☐P
424 / 538
6SL3320-1TE35-0AA☐
490
2
1FW3285-3☐J
376 / 400
6SL3320-1TE33-8AA☐
380
2
1FW3285-3☐M
469 / 532
6SL3320-1TE35-0AA☐
490
2
1FW3285-3☐P **
)
638 / 806
6SL3320-1TE38-4AA☐
731
2
1FW3287-3☐J **
)
504 / 534
6SL3320-1TE37-5AA☐
618
2
1FW3287-3☐M **
)
696 / 787
6SL3320-1TE38-4AA☐
731
2
1FW3287-3☐P **
)
830 / 830
6SL3320-1TE41-0AA☐
906
2
*
)
Other supply voltages can also be configured in SIZER.
**
)
The rated output current of the motor module includes a derating factor due to the pulse frequency.
Note
Sound pressure level when reducing the pulse frequency
When the pulse frequency is reduced, a significantly higher sound pressure level can occur.
