Siemens SINUMERIK 802D Training Manual

Notes
SINUMERIK 802D sl Operating and Service Training Manual Page 6
C77
C77
N10 G00 G90 G94 G40 G17
N20 T1 D1 ;End Mill D60mm
N30 G94 S424 F271 M03 M08
N40 G90 G54 G0 X-35 Y60 ; Basic settings, Start point
N50 G0 Z2
N60 G1 Z0
N70 X100
N80 Y20
N90 X-35
N100 G0 Y-35
N110 G1 Z-10 F1000
N120 G41 X5 ; Start the radius compensation
N130 Y70 RND=10 F271 ; Corner above left
N140 X72 Y70
N150 X92 Y58 ; Angle contour
N160 Y10 RND=15 ; Corner below right
N170 X4.5 ; End point 0.5mm further
N180 G40 Y-21 ; Cancel radius compensation
N190 G0 Z2
N200 Z100
N210 T2 D1 ; Slot Mill D6mm
N220 G94 S4200 F150 M04 M08
N230 G90 G54 G17 G0 X30 Y29
N240 G0 Z2
N250 G1 Z-5 ; Infeed into slot
N260 X70 F563
N270 G0 Z2 ; Bottom slot is finished
N280 X70 Y61 ; Start point top slot
N290 G1 Z-5 F150 ; Infeed top slot
N300 X30 F563
N310 G0 Z2 ; Top slot finished
N320 Z100 M5 M9 ; Retract tool
N330 X-200 Y150 ; Home position
N340 M30 ; Program end
Section 5
Create example program in editor
