Siemens SINUMERIK 802D Training Manual

Notes
SINUMERIK 802D sl Operating and Service Training Manual Page 3
C89
C89
Section 2
G function overview
Group 1: Modally valid motion commands
Name Meaning
Machine
G00 Rapid
traverse
M/T
G01*# Linear interpolation
M/T
G02 Circular interpolation clockwise
M/T
G03 Circular interpolation counter-clockwise
M/T
G33 Thread cutting with constant lead
M/T
Group 2: Non-modally valid motion, dwell
Name Meaning
Machine
G04
Dwell time preset
M/T
G63 Tapping without synchronization
M/T
G74 Reference point approach with synchronization
M/T
G75 Fixed point approach
M/T
Group 3: Programmable frame, working area limitation
Name Meaning
Machine
TRANS Translation,
programmable
M/T
ROT Rotation, programmable
M/T
SCALE Scaling, programmable
M/T
MIRROR Mirroring, programmable
M/T
G26
Maxi
mum working area limitation/spindle speed limi-
tation
M/T
G25
Minimu
m working area limitation/spindle speed limita-
tion
M/T
Group 6: Plane selection
Name Meaning
Machine
G17#
Plane selection 1st - 2nd geometry axis
M/T
G18* Plane selection 3rd - 1st geometry axis
M/T
G19 Plane selection 2nd - 3rd geometry axis
M/T
Default for turning * / default for milling #
M = milling / T = turnin
g
