Section 4
Define the program structure
The program sequence can be created from the work plan.
Tool 1: End mill D60mm
• Change tool
• Select the origin (absolut/incremental)
• Activate zero offset
• Define the work plane
• Program spindle speed and direction
• Program feedrate
• Switch coolant on
• Surface milling
• Position on the outside contour
• Contour milling
• Retract tool
• Stop spindle and coolant
Tool 2: Slot mill D6mm
• Change tool
• Select the origin (absolut/incremental)
• Activate zero offset
• Define the working plane
• Program spindle speed and direction
• Program feedrate
• Switch coolant on
• Slot milling
• Retract tool
• Stop spindle and coolant
• Return to home position
• Program end
4.1 Define the program structure
