Section 2
Principle of operation
2.1 Principle
of operation RCS802:
RCS —
R
emote Control System for the 802D SL CNC Controller.
The RCS80
2 tool works on the principle of creating a permanent online
connection to the CNC controller. This permanent connection
can be
RS232C or
Ethernet.
To connect
using RS232C the controller and the connected PC should
have the same configuration setting
s, Baud rate, stop bits etc.
To connect using Ethernet the controller and connected PC should have
compatible I
P addresses.
This online
connection permits a data transfer possibility over a long period
of time without a disrupt
ion in the transfer of data.
RS232C onl
ine connection:
The followin
g
sequence
of operations should be carried out to
obtain an
online seria
l connection to the controller:
1)
Start RCS 802
Click to start
RCS 80
2
appli
cation
The following screen can be seen:
Explorer
type window
Settings and
connection
status
Connection
type
Activate online con-
nection on/o
ff toggle
To Next Page
