Siemens SINUMERIK 802D Training Manual

Notes
SINUMERIK 802D sl Operating and Service Training Manual Page 5
C89
C89
Section 2
G function overview
Group 16: Feed override on inside and outside curvature
Name Meaning
Machine
CFC*#
Constant feed at contour
M/T
CFTCP Constant feed in tool center point (center-point path)
M/T
CFIN
Constant feed at interna
l radius, acceleration at exter-
nal radius
M/T
Group 15: Feed type
Name Meaning
Machine
G94#
Linear feed mm/min, inch/min
M/T
G95* Rotational feed in mm/rev, inch/rev
M/T
G96 Constant cutting speed (type of feed as for G95) ON
T
G97 Constant cutting speed (type of feed as for G95) OFF
T
Group 14: Workpiece measuring absolute/incremental
Name Meaning
Machine
G90*#
Absolute dimensions input
M/T
G91 Incremental dimension input
M/T
Group 13: Workpiece measuring inch/metric
Name Meaning
Machine
G70
Input system inches (lengths)
M/T
G71*# Input system metric (lengths)
M/T
Default for turning * / default for milling #
M = milling / T = turnin
g
