Siemens SINUMERIK 810D Programming Guide

8
04.00 Tool Offsets
8.5 Activate 3D tool offsets
8
840D
NCU 572
NCU 573
840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
8-279
Example
N10 A0 B0 X0 Y0 Z0 F5000
N20 T1 D1
Tool call, call tool offset values
N30 TRAORI(1)
Transformation selection
N40 CUT3DC
3D tool radius compensation selection
N50 G42 X10 Y10
Tool radius compensation selection
N60 X60
N70 …
Additional notes
Intermediate blocks are permitted with 3D tool radius
compensation. The rules for 2 1/2D tool radius
compensation apply.
3D tool radius compensation is only active when
five-axis transformation is selected.
A circle block is always inserted at outside corners.
G450/G451 have no effect.
The DISC command is ignored.
