Siemens SINUMERIK 840D

4
Protection Zones 08.97
4.1 Definin
g
the
p
rotection zones CPROTDEF
,
NPROTDEF
4
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
4-140
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
4.1 Defining the protection zones CPROTDEF, NPROTDEF
Programming
DEF INT NOT_USED
CPROTDEF(n,t,applim,applus,appminus)
NPROTDEF(n,t,applim,applus,appminus)
EXECUTE (NOT_USED)
Explanation of the commands
DEF INT NOT_USED
Locale variable, define data type integer (cf. Chapter 10)
CPROTDEF
Define channel-specific protection zones (for NCU 572/573 only)
NPROTDEF
Define machine-specific protection zones
EXECUTE
End definition
Explanation of the parameters
n
Number of defined protection zone
t
TRUE =
Tool
-oriented protection zone
FALSE =
Workpiece
-oriented protection zone
applim
Type of limit in the 3rd dimension
0 = No limit
1 = Limit in positive direction
2 = Limit in negative direction
3 = Limit in positive and negative direction
applus
Value of the limit in the positive direction in the 3rd dimension
appminus
Value of the limit in the negative direction in the 3rd dimension
NOT_USED
Error variable has no effect in protection zones with EXECUTE
