Siemens SINUMERIK 840D Programming Guide

12
Punching and Nibbling 08.97
12.1 Activation
,
deactivation
12
840 D
NCU 572
NCU 573
840Di

Siemens AG 2000. All rights reserved
12-416
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
12.1 Activation, deactivation
12.1.1 Language commands
Programming
PDELAYON
PON G... X... Y... Z...
PONS G... X... Y... Z...
PDELAYOF
SON G... X... Y... Z...
SONS G... X... Y... Z...
SPOF
Explanation of the parameters
PON
Punching on
PONS
Punching with leader on
SON
Nibbling on
SONS
Nibbling with leader on
SPOF
Punching, nibbling off
PDELAYON
Punching on with delay
PDELAYOF
Punching off with delay
Function
Punching and nibbling, activate/deactivate
PON/SON
The punching and nibbling functions are activated
with PON and SON respectively. SPOF terminates
all functions specific to punching and nibbling
operations.
Modal commands PON and SON are mutually
exclusive, i.e. PON deactivates SON and vice versa.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
