15
Tables 04.00
15.2 List of s
stem variables
15
ï›™
Siemens AG 2000. All rights reserved
15-532
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_MDP1
INT $TC_MDP1[n,m]
Distance between change position of magazine n and location m of
1st internal magazine
internal mag. 1 distance parameter
n: Physical Magazine number
m: Physical location number
RW 2
$TC_MDP2
INT $TC_MDP2[n,m]
Distance between change position of magazine n and location m of
2nd internal magazine
internal mag. 2 distance parameter
n: Physical Magazine number
m: Physical location number
RW 2
$TC_MLSR
INT $TC_MLSR[n,m]=0
Assignment between buffer location n and buffer location m
m must identify a location of type 'spindle'.
N must identify a location not of type 'spindle'.
This permits definition of the grippers are assigned to
which spindles. The parameter value fix = 0.
The write process defines a relation, the read process checks
whether a particular relation applies. If not, an alarm is produced
during a read operation.
Define links of grippers,... to spindles.
N: Physical magazine location number of location class not equal to
SPINDLE
m: Physical magazine location number of location class equal to
SPINDLE
RW 3
$TC_MPTH
INT $TC_MPTH[n,m]
Magazine location type hierarchy
mag.location (place)types hierarchy parameter
n: Hierarchy 0 – 7
m: Location type 0 – 7
RW 3
15.2.12 Magazine description data for tool management
$TC_MAP2
STRIN
G
$TC_MAP2[n]
Identifier of the magazine
n: Magazine number 1 to ...
RW 2
$TC_MAP1
INT $TC_MAP1[n]
Type of magazine
n: Magazine number 1 to ...
RW 2
$TC_MAP3
INT $TC_MAP3[n]
State of magazine
n: Magazine number 1 to ...
RW 2
$TC_MAP4
INT $TC_MAP4[n]
Chaining with following magazine
n: Magazine number 1 to ...
RW 2
