14
User Stock Removal Programs 12.98
14.1 Su
ortin
functions for stock removal
14
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di
ï›™
Siemens AG 2000. All rights reserved
14-464
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
14.1 Supporting functions for stock removal
User stock removal programs
Preprogrammed stock removal programs are
provided for stock removal. You can also use the
following functions to develop your own stock
removal programs.
CONTPRON
Activate tabular contour preparation (11 columns)
CONTDCON
Activate tabular contour decoding (6 columns)
INTERSEC
Calculate intersection of two contour elements
(Only for tables created by CONTPRON).
EXECTAB
Block-by-block execution of contour elements of a table
(Only for tables created by CONTPRON).
CALCDAT
Calculate radii and center points
You can use these functions universally, not just for
stock removal.
