12.98 Frames
6
Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
6-191
Frames
6.1 Coordinate transformation via frame variables ............................................................. 6-192
6.2 Frame variables/assigning values to frames ................................................................ 6-197
6.3 Coarse/fine offset......................................................................................................... 6-204
6.4 DRF offset.................................................................................................................... 6-205
6.5 External zero offset ...................................................................................................... 6-206
6.6 Programming Preset offset, PRESETON .................................................................... 6-207
6.7 Deactivating frames ..................................................................................................... 6-208
6.8 Frame calculation from three measuring points in the area, MEAFRAME .................. 6-209
6.9 NCU-global frames (SW 5 and higher)........................................................................ 6-212
6.9.1 Channel-specific frames............................................................................................ 6-213
6.9.2 Frames active in the channel .................................................................................... 6-215
