Siemens SINUMERIK 840D Programming Guide

15
04.00 Tables
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-529
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_TPCS2
REAL The type can be defined in the machine data. The default is INT
$TC_TPCS2[t]
t: T number 1–32000
RW 5
.
2
...
...
$TC_TPCS10
REAL The type can be defined in the machine data. The default is INT
$TC_TPCS10[t]
t: T number 1–32000
RW 5
.
2
15.2.9 Tool-related grinding data
$TC_TPG1
INT $TC_TPG1[t]
Spindle number
t: T number 1–32000
RW 2
$TC_TPG2
INT $TC_TPG2[t]
Chaining rule
t: T number 1–32000
RW 2
$TC_TPG3
REAL $TC_TPG3[t]
Minimum grinding wheel radius
t: T number 1–32000
RW 2
$TC_TPG4
REAL $TC_TPG4[t]
Minimum grinding wheel width
t: T number 1–32000
RW 2
$TC_TPG5
REAL $TC_TPG5[t]
Current grinding wheel width
t: T number 1–32000
RW 2
$TC_TPG6
REAL $TC_TPG6[t]
Maximum rotation speed
t: T number 1–32000
RW 2
$TC_TPG7
REAL $TC_TPG7[t]
Maximum surface speed
t: T number 1–32000
RW 2
$TC_TPG8
REAL $TC_TPG8[t]
Inclination angle for oblique grinding wheel
t: T number 1–32000
RW 2
$TC_TPG9
INT $TC_TPG9[t]
Parameter number for radius calculation
t: T number 1–32000
RW 2

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
