Siemens SINUMERIK 840D

15
Tables 04.00
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
15-510
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15.2.3 Toolholder data
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_CARR1
REAL $TC_CARR1[n]
x component of offset vector l1
Caution! All system parameters with the '$TC_' prefix are contained
in the TOA area.
The specialty in this area is that various channels of the NCI can
access these parameters when machine data 28085 =
MM_LINK_TOA_UNIT.
If this parameterization mode is chosen for the NCK, you must be
aware of the fact that changes may interfere with an other channel;
i.e. you must make sure that the change only affects the local
channel.
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR2
REAL $TC_CARR2[n]
y component of offset vector l1
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR3
REAL $TC_CARR3[n]
z component of offset vector l1
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR4
REAL $TC_CARR4[n]
x component of offset vector l2
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR5
REAL $TC_CARR5[n]
y component of offset vector l2
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR6
REAL $TC_CARR6[n]
z component of offset vector l2
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR7
REAL $TC_CARR7[n]
x component of axis of rotation v1
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
