Siemens SINUMERIK 840D Programming Guide

15
04.00 Tables
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-511
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_CARR8
REAL $TC_CARR8[n]
y component of axis of rotation v1
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR9
REAL $TC_CARR9[n]
z component of axis of rotation v1
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR10
REAL $TC_CARR10[n]
x component of axis of rotation v2
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR11
REAL $TC_CARR11[n]
y component of axis of rotation v2
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR12
REAL $TC_CARR12[n]
z component of axis of rotation v2
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR13
REAL $TC_CARR13[n]
Angle of rotation alpha1 (in degrees)
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR14
REAL $TC_CARR14[n]
Angle of rotation alpha2 (in degrees)
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 4
$TC_CARR15
REAL $TC_CARR15[n]
x component of basic vector b
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 5
$TC_CARR16
REAL $TC_CARR16[n]
y component of basic vector b
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 5
$TC_CARR17
REAL $TC_CARR17[n]
z component of basic vector b
The max. number of toolholders can be set via machine data.
Default setting is = 0; i.e. NCI has no such data.
RW 5
