15.2.7 Monitoring data for OEM users
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_MOPC1
INT The type can be defined in the machine data. The default is INT
$TC_MOPC1[t,d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_MOPC2
INT The type can be defined in the machine data. The default is INT
$TC_MOPC2[t,d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
...
...
$TC_MOPC10
INT The type can be defined in the machine data. The default is INT
$TC_MOPC10[t,d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_MOPCS1
INT The type can be defined in the machine data. The default is INT
$TC_MOPCS1[t,d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
.
2
$TC_MOPCS2
INT The type can be defined in the machine data. The default is INT
$TC_MOPCS2[t,d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
.
2
...
...
$TC_MOPCS10
INT The type can be defined in the machine data. The default is INT
$TC_MOPCS10[t,d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
.
2
15.2.8 Tool-related data
$TC_TP1
INT $TC_TP1[t]
Duplo number
t: T number 1–32000
RW 2
$TC_TP2
STRIN
G
$TC_TP2[t]
Tool name
t: T number 1–32000
RW 2
$TC_TP3
INT $TC_TP3[t]
Size to left
t: T number 1–32000
RW 2
