Page #534 background image
15
Tables 04.00
15.2 List of s
y
stem variables
15
ï›™
Siemens AG 2000. All rights reserved
15-534
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15.2.14 Magazine module parameter
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_MAMP1
STRIN
G
$TC_MAMP1
Identifier of the magazine module
Scalar variable
RW 2
$TC_MAMP2
INT $TC_MAMP2
Type of tool search
Scalar variable
RW 2
$TC_MAMP3
INT $TC_MAMP3
Handling of tools with wear groups
Scalar variable
RW 5
Adapter data
$TC_ADPTT
INT $TC_ADPTT[a]
Adapter transformation number
a: Adapter number 1–32000
RW 5
$TC_ADPT1
REAL $TC_ADPT1[a]
Adapter geometry: Length 1
a: Adapter number 1–32000
RW 5
$TC_ADPT2
REAL $TC_ADPT2[a]
Adapter geometry: Length 2
a: Adapter number 1–32000
RW 5
$TC_ADPT3
REAL $TC_ADPT3[a]
Adapter geometry: Length 3
a: Adapter number 1–32000
RW 5
15.2.15 Measuring system compensation values
$AA_ENC_COMP
REAL $AA_ENC_COMP[n,m,a]
Compensation values
a: Machine axis
n: Encoder no. 0–1
m: Point no. 0 – <MD value>
Axes: Machine axis
RW 2
$AA_ENC_COMP
_STEP
REAL $AA_ENC_COMP_STEP[n,a]
Step width
a: Machine axis
n: Encoder no. 0–1
Axes: Machine axis
RW 2
$AA_ENC_COMP
_MIN
REAL $AA_ENC_COMP_MIN[n,a]
Compensation start position
a: Machine axis
n: Encoder no. 0–1
Axes: Machine axis
RW 2
$AA_ENC_COMP
_MAX
REAL $AA_ENC_COMP_MAX[n,a]
Compensation end position
a: Machine axis
n: Encoder no. 0–1
Axes: Machine axis
RW 2
