Siemens SINUMERIK 840D Programming Guide

15
04.00 Tables
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-563
15.2.44 Oscillation
Identifier Type Description: System variable/value range/index Part pro Sync O S
$AA_DTEPW
REAL $AA_DTEPW[X]
Axial distance-to-go for infeed oscillation in
workpiece coordinate system
This variable can only be accessed from synchronized actions
Axes: Channel axis
RS R 2
$AA_DTEPB
REAL $AA_DTEPB[X]
Axial distance-to-go for infeed oscillation in basic coordinate system
This variable can only be accessed from synchronized actions
Axes: Channel axis
RS R 2
$AA_OSCILL_RE
VERSE_POS1
REAL $AA_OSCILL_REVERSE_POS1[X]
Current reversal position 1 for oscillation
In synchronized actions, the setting data value
$SA_OSCILL_REVERSE_POS1 is evaluated online
This variable can only be accessed from synchronized actions
Axes: Channel axis
RS R 3
$AA_OSCILL_RE
VERSE_POS2
REAL $AA_OSCILL_REVERSE_POS2[X]
Current reversal position 2 for oscillation
In synchronized actions, the setting data value
$SA_OSCILL_REVERSE_POS2 is computed online
This variable can only be accessed from synchronized actions
Axes: Channel axis
RS R 3
$AA_DELT
REAL $AA_DELT[X]
Latched axial residual path distance in workpiece coordinate system
after axial delete distance-to-go with motion-synchronized actions
Axes: Geometry axis, channel axis, machine axis
R2
$P_FA
REAL $P_FA[X]
Axis feed last programmed
Axes: Channel axis
R2

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
