Page #341 background imageLoading...
Page #341 background image
10
12.97 Motion-Synchronous Action
10.1 Structure
,
basic information
10
840 D
NCU 571
840D
NCU 572
NCU 573
FM-NC
810D
CCU2
840Di
ï›™
Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
10-341
Possible applications
:
•
Optimization of runtime-critical applications
(e.g. tool changing)
•
Fast response to an external event
•
Programming AC controls
•
Setting up safety functions
•
....
10.1.1 Programming and command elements
Function
A synchronized action is programmed on its own in a
separate block and triggers a machine function in
the next executable block (e.g. traversing movement
with G0, G1, G2, G3; block with auxiliary function
output).
Synchronized actions consist of up to five command
elements each with a different task:
ID n um ber:
Scope of validity
Vocabulary word:
Scan frequency
opt. G code
for condition
Condition
DO
opt. G cod e for
action/techno. c.
Action
Technology
cycle
Example:
ID=1
WHENEVER
$A_IN[1]==1
DO
$A_OUT[1]=1
Synchronized action no. 1:
whenever
input 1 is set
then
set output 1
