15
Tables 04.00
15.2 List of s
stem variables
15
ï›™
Siemens AG 2000. All rights reserved
15-514
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$SC_PA_CONT_T
YP
INT $SC_PA_CONT_TYP"[n,m]
Contour element type (G1, G2, G3)
n: No. of protection zone 0 – (maximum value can be set via MD)
m: Number of contour element 0 – 10
RW 2
$SC_PA_CONT_
ORD
REAL $SC_PA_CONT_ORD[n,m]
End point of contour element (ordinate)
n: No. of protection zone 0 – (maximum value can be set via MD)
m: Number of contour element 0 – 10
RW 2
$SC_PA_CONT_
ABS
REAL $SC_PA_CONT_ABS[n,m]
End point of contour element (abscissa)
n: No. of protection zone 0 – (maximum value can be set via MD)
m: Number of contour element 0 – 10
RW 2
$SC_PA_CENT_
ORD
REAL $SC_PA_CENT_ORD[n,m]
Center point of contour element (ordinate)
n: No. of protection zone 0 – (maximum value can be set via MD)
m: Number of contour element 0 – 10
RW 2
$SC_PA_CENT_A
BS
REAL $SC_PA_CENT_ABS[n,m]
Center point of contour element (abscissa)
n: No. of protection zone 0 – (maximum value can be set via MD)
m: Number of contour element 0 – 10
RW 2
15.2.5 Tool parameters
$TC_DP1
INT $TC_DP1[t,d]
Tool type
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP1[d]
t: T number 1–32000
d: Cutting edge number/D number 1–9
RW 2
$TC_DP2
REAL $TC_DP2[t,d]
Tool edge position
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP2[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP3
REAL $TC_DP3[t,d]
Geometry – Length 1
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP3[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
