Siemens SINUMERIK 840D

15
04.00 Tables
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-515
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_DP4
REAL $TC_DP4[t,d]
Geometry – Length 2
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP4[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP5
REAL $TC_DP5[t,d]
Geometry – Length 3
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP5[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP6
REAL $TC_DP6[t,d]
Geometry – Radius
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP6[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP7
REAL $TC_DP7[t,d]
Slotting saw: Corner radius
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP7[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP8
REAL $TC_DP8[t,d]
Slotting saw: Length
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP8[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP9
REAL $TC_DP9[t,d]
Reserved
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP9[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
