Siemens SINUMERIK 840D Programming Guide

8
04.00 Tool Offsets
8.3 Online tool offset PUTFTOCF
,
PUTFTOC
,
FTOCON
,
FTOCOF
8
840D
NCU 572
NCU 573
840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
8-269
8.3 Online tool offset PUTFTOCF, PUTFTOC, FTOCON, FTOCOF
Programming
FCTDEF(Polynomial no., LLimit, ULimit,a
0
,a
1
,a
2
,a
3
)
PUTFTOCF(Polynomial No., Ref_value, Length1_2_3, Channel, Spindle)
PUTFTOC(Value, Length1_2_3, Channel, Spindle)
FTOCON
Explanation of the commands
PUTFTOCF
Write online tool offsets continuously
FCTDEF
Define parameters for PUTFTOCF function
PUTFTOC
Write online tool offsets discretely
FTOCON
Activate online tool offsets
FTOCOF
Deactivate online tool offsets
Explanation of the parameters
Polynomial_No.
Values 1
−
3: a maximum of three polynomials can be programmed at
the same time; polynomials up to 3rd degree
Ref_value
Reference value from which the offset is derived
Length1_2_3
Wear parameter into which the tool offset value is added
Channel
Number of channel in which the tool offset is activated; specified only if
the channel is different to the present one
Spindle
Number of the spindle on which the online tool offset acts; only needs to
be specified for inactive grinding wheels
LLimit
Lower limit
ULimit
Upper limit
a
0
,a
1
,a
2
,a
3
Coefficients of polynomial function
Value
Value added in the wear parameter

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
