Flexible NC Programming 02.98
1.16 NEWCONF: Settin
machine data active
as from SW 4.3
1
840D
NCU 571
840D
NCU 572
NCU 573
810D
840Di
ï›™
Siemens AG 2000. All rights reserved
1-80
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
1.16 NEWCONF: Setting machine data active (as from SW 4.3)
Function
All machine data of the effectiveness level
"NEW_CONFIG" are set active by means of the
NEWCONF language command. The function
corresponds to activating the softkey "Set MD
active".
When the NEWCONF function is executed there is
an implicit preprocessing stop, that is, the path
movement is interrupted.
Explanation
NEWCONF
All machine data of the "NEW_CONFIG" effectiveness level are set active
Programming example
Milling operation: Machining drilling position with
different technologies
N10 $MA_CONTOUR_TOL[AX]=1.0
; Change machine data
N20 NEWCONF
; Set machine data active
