Siemens SINUMERIK 840D Programming Guide

6
Frames 12.98
6.7 Deactivatin
g
frames
6
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
6-208
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
6.7 Deactivating frames
Explanation of the commands
DRFOF
Deactivate (clear) the handwheel offsets (DRF)
G53
Non-modal deactivation of programmable and all settable frames
G153
Non-modal deactivation of programmable frames, base frames and all
settable frames
SUPA
Non-modal deactivation of all programmable frames, base frames, all
settable frames and handwheel offsets (DRF)
Additional notes
The programmable frames are cleared by assigning
a "zero frame" (without axis specification) to the
programmable frame.
Example:
$P_PFRAME=TRANS( )
$P_PFRAME=ROT( )
$P_PFRAME=SCALE( )
$P_PFRAME=MIRROR( )

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
