Siemens SINUMERIK 840D Programming Guide

15
Tables 04.00
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
15-528
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_TP4
INT $TC_TP4[t]
Size to right
t: T number 1–32000
RW 2
$TC_TP5
INT $TC_TP5[t]
Size toward top
t: T number 1–32000
RW 2
$TC_TP6
INT $TC_TP6[t]
Size toward bottom
t: T number 1–32000
RW 2
$TC_TP7
INT $TC_TP7[t]
Magazine location type
t: T number 1–32000
RW 2
$TC_TP8
INT $TC_TP8[t]
Status
t: T number 1–32000
RW 2
$TC_TP9
INT $TC_TP9[t]
Type of tool monitoring
t: T number 1–32000
RW 2
$TC_TP11
INT $TC_TP11[t]
Replacement strategy
t: T number 1–32000
RW 2
$TC_TP10
INT $TC_TP10[t]
Tool info
t: T number 1–32000
RW 2
$TC_TPC1
REAL The type can be defined in the machine data. The default is INT
$TC_TPC1[t]
t: T number 1–32000
RW 2
$TC_TPC2
REAL The type can be defined in the machine data. The default is INT
$TC_TPC2[t]
t: T number 1–32000
RW 2
...
... ...
$TC_TPC10
REAL The type can be defined in the machine data. The default is INT
$TC_TPC10[t]
t: T number 1–32000
RW 2
$TC_TPCS1
REAL The type can be defined in the machine data. The default is INT
$TC_TPCS1[t]
t: T number 1–32000
RW 5
.
2

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
