5.6 Measurements with touch tri
gg
er
p
robe
,
MEAS
,
MEAW
5
840D
NCU 571
840D
NCU 572
NCU 573
810D
CCU 2
840Di

Siemens AG 2000. All rights reserved
5-176
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
Measured value recording
The positions of all path and positioning axes
(maximum number of axes depends on control
configuration) in the block that have moved are
recorded.
In the case of MEAS, the motion is braked in a
defined manner after the probe has switched.
Comment
If a GEO axis is programmed in a measurement
block, the measured values for all current GEO axes
are recorded.
If an axis that participates in a transformation is
programmed in a measurement block, the measured
values for all axes that participate in this
transformation are recorded.
Additional notes
The MEAS and MEAW functions are active non-
modally.
